The cases below are sourced from pages 5–6 of the official DDHC 2027 product manual and showcase our non-standard customization capabilities for research and industrial customers — from integrated multi-axis motion platforms and high-/low-temperature environmental adaptations to ultra-thin lifting stages, custom-shaped platforms and gimbal systems, all designed and manufactured one-to-one against customer specifications and operating conditions.
Overview (manual pages 5–6)
All 11 Custom Cases
Case 01
Integrated XY Motorized Stage
- Integrated XY design
- X / Y travel ±10 mm
- Footprint 90 mm × 90 mm × 65 mm
- 2-phase stepper motor drive
Case 02
Integrated Pitch–Yaw Stage
- Integrated pitch–yaw design
- Aluminium body
- Yaw range ±2.5°
- Pitch +4° to −2°
- Max. load 1 kg
Case 03
Manual 6-axis Integrated Stage
- Manual 6-axis integrated design
- Aluminium body
- X / Y / Z travel 50 mm, pitch–yaw ±10°, rotation ±5°
Case 04
Motorized 6-axis Stage
- Motorized 6-axis, tandem design
- Aluminium body
- X / Y / Z travel 50 mm, pitch–yaw ±10°, continuous 360° rotation
Case 05
Custom Tiled Platform
- Stainless-steel top
- Custom-shaped tiles
- Damping isolation
Case 06
Gantry Structure
- Dual-axis synchronized drive
- Aluminium body
- X / Y travel 400 mm, Z travel 100 mm
Case 07
8-station Low-temperature Turntable
- Two rotation axes, individually or jointly controlled
- Multi-station adjustment
- Operating temperature −45 °C to +85 °C
Case 08
High-/Low-temperature Gimbal System
- Two rotation axes, individually or jointly controlled
- Gimbal adjustment, continuous rotation > 360°
- Operating temperature −45 °C to +85 °C
Case 09
Custom Optic Mounts
- Mount dimensions and surface finish tailored to customer requirements
Case 10
Ultra-thin Manual Lift Stage
- Table size 200 mm × 200 mm
- Aluminium body
- 60 mm manual travel, minimum height 70 mm
- Max. load 80 kg
Case 11
Custom 3-axis System
- Various table-size and travel options
- Aluminium body
For a similar solution or any special operating condition, please send us your technical specifications (travel / load / accuracy / environment / interface) and our engineering team will respond with a feasibility study and quotation within 24 hours.
