MARB Series 3-Axis Manual Fiber Adjustment Mounts
ModelMARB Series中文页面 ↗
- Single-axis precision screw drive
- Table sizes: multiple options
- Coarse 360°, fine ±5° or ±10°
- Lapped or crossed-roller bearing guides
+86 137 1698 9256 Ms. Liu · sally-liu@ddhc-tech.com
Custom and OEM designs are welcome — contact us for pricing and selection support.
Specifications
| Model | MARB Series |
|---|---|
| Series | MARB |
| Category | Fiber Optic Alignment Stages |
| Motion | Translation |
| Available Models | MARB70-2, MARB70-3 (2 models; integrated-guide multi-axis stage; -2: θX +4°~−2°, θZ ±2.5°, load 0.5 kg; -3: θX/θY ±3°, θZ ±10°, load 3 kg, aluminium) |
| Naming Convention | M=manual; A=aluminium (S=stainless steel); R=rotation adjustment; B=integrated guide (C=crossed roller guide); 70=table size (mm); trailing digit=adjustment axes (2/3 axes) |
| Center Load | 0.5 / 3 kg |
| Weight | 0.2 / 0.5 kg |
| Drive Position | Center (3-axis micrometer heads: tilt + rotation + yaw) |
| Table Size | φ70 mm |
| Guide Type | Multi-axis mix: crossed roller + dovetail |
| Body Material | Aluminum alloy, black anodized |
| Note | Specifications compiled from the product selection chart; refer to the latest factory data. |
| Source SKU | 12261410 |
Specifications shown are typical values; detailed drawings and full specifications are available on request. OEM and custom designs are welcome.
